Wieland WKFN 4 FSI Fuse Terminal Block - DIN Rail Mount
Wieland WKFN 4 FSI Fuse Terminal Block - DIN Rail Mount
SKU:DIN-b5d0ad
Reliable Wieland WKFN 4 FSI Fuse Terminal Block for secure electrical connections on TS 35 DIN rail. Nominal 4mm² cross-section, 400V max rated voltage, UL94 V0 insulating housing. RoHS & REACH compliant.
Regular price
$22.99
Regular price
Sale price
$22.99
Unit price
per
Initiate Order
Wieland WKFN 4 FSI Fuse Terminal Block - DIN Rail Mount
$22.99
Quantity: 1
Claim Your Seller Account
Wieland WKFN 4 FSI Fuse Terminal Block - DIN Rail Mount
$22.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland WKFN 4 FSI Fuse Terminal Block is a high-quality solution designed for secure electrical connections. This terminal block features a tension spring connection for easy installation on a TS 35 DIN rail. With a nominal cross-section of 4mm², it provides reliable performance with a maximum rated voltage of 400V. The UL94 V0-rated insulating housing ensures safety and durability, meeting RoHS and REACH-SVHC conformity standards. Ideal for electrical installations, this fuse terminal block is a top choice for both institutional and consumer buyers.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27141116
Classification Etim 30 Classification
EC000899
Classification Etim 40 Classification
EC000899
Classification Etim 50 Classification
EC000899
Classification Etim 60 Classification
EC000899
Classification Etim 70 Classification
EC000899
Connection Data Connection Type 1
Spring Clamp Connection
Connection Data Connection Type 2
Spring Clamp Connection
Connection Data Maximum Fine Stranded Cross Section
4 mm²
Connection Data Maximum Solid Cross Section
6 mm²
Connection Data Minimum Fine Stranded Cross Section
0.13 mm²
Connection Data Minimum Solid Cross Section
0.13 mm²
Connection Data Wire Strip Length
11 mm
General Brands
Wieland
General Color
Gray
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WKFN 4 FSI
General Mounting Method
DIN Rail (Top Hat Rail)
General Mounting Size
35 x 7.5 mm
General Nominal Cross Section
4 mm²
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
No
General Width Grid Dimension
6 mm
Note Defect Indicator
None
Note Remark To Maximum Rated Voltage
Note fuse insert
Note Remark To Rated Current
Note Fuse Insert
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
Yes
Technical Data Fuse Insert
Blade Fuse
Technical Data Length
82.2 mm
Technical Data Maximum Rated Voltage
400 V
Technical Data Pollution Degree
3
Technical Data Rated Impulse Voltage
6 kV
Technical Data Type Of Insulation Material
Thermoplastic
