Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

DIN-a9ec29

Reliable Wieland WKM terminal block with 2.5 mm² cross-section, DIN rail mount, V0 inflammability class, and RoHS compliance.

$12.99
$12.99
Sale

Initiate Order

Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

$12.99

Quantity: 1

Claim Your Seller Account

Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

Wieland WKM 2.5/15/V0 Feed-Through Terminal Block

$12.99

Quantity: 1

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details
The Wieland WKM 2.5/15/V0 Feed-Through Terminal Block features a nominal cross-section of 2.5 mm², rated current of 25 A, and maximum rated voltage of 500 V. With a V0 inflammability class for the insulating housing, it ensures top-notch safety. This terminal block is designed for DIN rail mounting and offers reliable screw connections, making it ideal for electrical installations that demand precision and durability. Compliant with RoHS and REACH-SVHC standards, this terminal block is a high-quality choice for both consumer and institutional buyers.

Ready to Grow Without Cash Flow Constraints?

Get Net 30, 60, or 90 day terms at 0% interest on any purchase

Check Your Eligibility Now
Ready to Grow Without Cash Flow Constraints?

Product Specifications

Classification Eclass 81 Classification
27141120
Classification Etim 30 Classification
EC000897
Classification Etim 40 Classification
EC000897
Classification Etim 50 Classification
EC000897
Classification Etim 60 Classification
EC000897
Classification Etim 70 Classification
EC000897
Connection Data Connection Type 1
Screw Connection
Connection Data Connection Type 2
Screw Connection
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
4 mm²
Connection Data Minimum Fine Stranded Cross Section
0.5 mm²
Connection Data Minimum Solid Cross Section
0.5 mm²
Connection Data Wire Strip Length
9 mm
General Brands
Wieland
General Color
Gray
General Explosion Tested Version Ex E
Yes
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WKM 2,5/15/V0
General Mounting Method
DIN Rail (Top Hat Rail)
General Nominal Cross Section
2.5 mm²
General Number Of Clamp Positions Per Level
2
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
Yes
General Width Grid Dimension
5 mm
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
Yes
Technical Data Length
32 mm
Technical Data Maximum Rated Voltage
500 V
Technical Data Pollution Degree
3
Technical Data Rated Current
25 A
Technical Data Rated Impulse Voltage
6 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Canadian Standards Associatio
22-12 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
22-14 AWG
Technical Data Ulcsa Current Canadian Standards Association Csa
25 A
Technical Data Ulcsa Factory Wiring Current
10 A
Technical Data Ulcsa Voltage Canadian Standards Association Csa
600 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
