Wieland WKMF 2.5 SL/15 Earth Terminal Block
Wieland WKMF 2.5 SL/15 Earth Terminal Block
SKU:DIN-eb2eac
Reliable Wieland WKMF 2.5 SL/15 Earth Terminal Block for secure grounding in electrical installations, compliant with RoHS & REACH-SVHC.
Regular price
$12.99
Regular price
Sale price
$12.99
Unit price
per
Initiate Order
Wieland WKMF 2.5 SL/15 Earth Terminal Block
$12.99
Quantity: 1
Claim Your Seller Account
Wieland WKMF 2.5 SL/15 Earth Terminal Block
$12.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland WKMF 2.5 SL/15 Earth Terminal Block is a high-quality grounding solution designed for electrical installations. With a nominal cross section of 2.5mm² and a width of 5.1mm, this terminal block features a tension spring connection for secure mounting on TS 15 DIN rails. The green-yellow color ensures easy identification. It complies with RoHS and REACH-SVHC standards, offering reliability and safety in line with industry regulations.
Product Specifications
Classification Eclass 81 Classification
27141141
Classification Etim 30 Classification
EC000901
Classification Etim 40 Classification
EC000901
Classification Etim 50 Classification
EC000901
Classification Etim 60 Classification
EC000901
Classification Etim 70 Classification
EC000901
Connection Data Connection Type 1
Spring Clamp Connection
Connection Data Connection Type 2
Spring Clamp Connection
Connection Data Maximum Fine Stranded Cross Section
2.5 mm²
Connection Data Maximum Solid Cross Section
2.5 mm²
Connection Data Minimum Fine Stranded Cross Section
0.13 mm²
Connection Data Minimum Solid Cross Section
0.13 mm²
Connection Data Wire Strip Length
10 mm
General Brands
Wieland
General Color
Green/Yellow
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WKMF 2,5 SL/15
General Mounting Method
DIN Rail (Top Hat Rail)
General Mounting Size
15 mm
General Nominal Cross Section
2.5 mm²
General Number Of Clamp Positions Per Level
2
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
Yes
General Width Grid Dimension
5.1 mm
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
Yes
Technical Data Length
35 mm
Technical Data Pollution Degree
3
Technical Data Rated Impulse Voltage
6 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Canadian Standards Associatio
26-12 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
26-12 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
600 V
