The Wieland WRT 35/M6 High Current Terminal Block is a top-of-the-line solution designed for robust electrical installations. With a nominal cross-section of 35 mm² and a rated current of 125 A, this terminal block ensures reliable and efficient power distribution. It features a bolt connection for secure wiring, meets UL/CSA standards for voltage and current ratings, and is constructed with high-quality insulating materials for safety and durability. Ideal for DIN rail mounting, this gray terminal block is compact yet powerful, making it a perfect choice for demanding industrial and institutional applications.
Product Specifications
Classification Eclass 81 Classification
27141120
Classification Etim 50 Classification
EC000897
Classification Etim 60 Classification
EC000897
Classification Etim 70 Classification
EC000897
Connection Data Connection Type
Bolt Connection
Connection Data Connection Type 1
Bolt Connection
Connection Data Maximum Fine Stranded Cross Section
50 mm²
Connection Data Minimum Fine Stranded Cross Section
2.5 mm²
General Brands
Wieland
General Color
Gray
General Explosion Tested Version Ex E
No
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA66
General Model
WRT 35/M6
General Mounting Method
DIN Rail (Top Hat Rail)
General Mounting Size
35 mm
General Nominal Cross Section
35 mm²
General Number Of Clamp Positions Per Level
2
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
Yes
General Width Grid Dimension
27 mm
Product Compliance Reach Svhc Conformity Status
Compliant
Technical Data Height
51.5 mm
Technical Data Length
107.5 mm
Technical Data Maximum Rated Voltage
1000 V
Technical Data Pollution Degree
3
Technical Data Rated Current
125 A
Technical Data Rated Impulse Voltage
8 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Canadian Standards Associatio
14 - 2 AWG
Technical Data Ulcsa Cross Section Underwriters Laboratories Ul
14 - 2 AWG
Technical Data Ulcsa Current Canadian Standards Association Csa
130 A
Technical Data Ulcsa Factory Wiring Current
130 A
Technical Data Ulcsa Voltage Canadian Standards Association Csa
1000 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
1000 V
Technical Data Width
27 mm
