Wieland WT 4 D2/2 BL Feed-Through Terminal Block
Wieland WT 4 D2/2 BL Feed-Through Terminal Block
SKU:DIN-b8e30f
High-quality Wieland WT 4 D2/2 BL Feed-Through Terminal Block for secure electrical connections on DIN rails. Compliant with RoHS & REACH-SVHC.
Regular price
$24.99
Regular price
Sale price
$24.99
Unit price
per
Initiate Order
Wieland WT 4 D2/2 BL Feed-Through Terminal Block
$24.99
Quantity: 1
Claim Your Seller Account
Wieland WT 4 D2/2 BL Feed-Through Terminal Block
$24.99
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Wieland WT 4 D2/2 BL Feed-Through Terminal Block is a high-quality DIN rail terminal block designed for electrical installations. With a nominal cross-section of 4 mm² and a rated current of 32 A, it ensures reliable connections up to 500 V. Featuring screw connections, PA666 insulating housing, and UL94 V0 flame resistance, this terminal block meets stringent industry standards. Its compact dimensions of 68mm x 6mm x 49mm make it space-efficient for various applications. Suitable for both solid and stranded conductors, this terminal block is RoHS and REACH-SVHC compliant, ensuring environmental responsibility.
Ready to Grow Without Cash Flow Constraints?
Product Specifications
Classification Eclass 81 Classification
27141120
Classification Etim 30 Classification
EC000897
Classification Etim 40 Classification
EC000897
Classification Etim 50 Classification
EC000897
Classification Etim 60 Classification
EC000897
Classification Etim 70 Classification
EC000897
Connection Data Connection Type 1
Screw Connection
Connection Data Connection Type 2
Screw Connection
Connection Data Maximum Conductor Cross Section Flexible Strande
4
Connection Data Maximum Fine Stranded Cross Section
6 mm²
Connection Data Maximum Solid Cross Section
6 mm²
Connection Data Minimum Conductor Cross Section Flexible Strande
0.5
Connection Data Minimum Fine Stranded Cross Section
0.14 mm²
Connection Data Minimum Solid Cross Section
0.14 mm²
Connection Data Wire Strip Length
9 mm
General Brands
Wieland
General Color
Blue
General Inflammability Class Of Insulation Material According Wi
V0
General Insulating Housing
PA666
General Model
WT 4 D2/2 BL
General Mounting Method
DIN Rail (Top Hat Rail)
General Nominal Cross Section
4 mm²
General Number Of Clamp Positions Per Level
4
General Number Of Levels
1
General Terminal Blocks For Electrical Installations
Yes
General Width Grid Dimension
6 mm
Product Compliance Reach Svhc Conformity Status
Compliant
Product Compliance Rohs Conformity Status
Compliant
Technical Data Closing Plate Required
Yes
Technical Data Height
49 mm
Technical Data Length
68 mm
Technical Data Maximum Rated Voltage
500 V
Technical Data Pollution Degree
3
Technical Data Rated Current
32 A
Technical Data Rated Impulse Voltage
6 kV
Technical Data Type Of Insulation Material
Thermoplastic
Technical Data Ulcsa Cross Section Canadian Standards Associatio
26-10 AWG
Technical Data Ulcsa Voltage Canadian Standards Association Csa
300 V
Technical Data Ulcsa Voltage Underwriters Laboratories Ul
300 V
Technical Data Width
6 mm
