Reliable Series EVML Gear Operated DIN Butterfly Valve with diverse body materials and superior performance capabilities.

$699.99

Sale

Quantity

Delivery via Maden

Expect your order to arrive on time.

Secure Payments

All orders are processed through a secure, PCI-compliant checkout.

View full details

The Series EVML Gear Operated Cast Iron Mono Flanged DIN Butterfly Valve, with a reliable valve function for isolating and regulating, offers a robust construction featuring various body materials such as GG25 Cast Iron and Ductile Iron. Equipped with a Shaft Material of Stainless Steel, Stem Material options including Aluminum Bronze, and Pressure rating of PN 10, this valve ensures exceptional performance and durability. With a Weight of 115.0 kg and compliance with DIN standard, this valve is ideal for industrial applications requiring precision and reliability.

Product Specifications

Specifications A

436 mm

Specifications Actuation Possibilities

Gear

Specifications Available Type Approvals

ABS | BV | DNV | DVGW | FM | GL | KIWA | LRS | RIN | RMRS | WRC

Specifications Body Material

Cast Iron

Specifications B Diameter

522 mm

Specifications C

152 mm

Specifications D

334 mm

Specifications E

388 mm

Specifications F

25 mm

Specifications Flange Connections

PN 10

Specifications G

50 mm

Specifications H Diameter

30 mm

Specifications Iso 5211

F14

Specifications K

140 mm

Specifications L

175 mm

Specifications Liner Material

Ethylene Propylene Diene Monomer (EPDM)

Specifications M Diameter

17 mm

Specifications N Number Of Holes

Specifications Pressure

PN 10

Specifications S

28 mm

Specifications Shaft Material

Stainless Steel 1.4462

Specifications Size

DN450 - 18" | 450 mm

Specifications Standard

DIN

Specifications Stem Material

Aluminum Bronze | Duplex Stainless Steel 1.4462 | Martensitic Stainless Steel 1.4408

Specifications T

54 mm

Specifications Valve Function

Isolating valve (on,off) and regulating valve | Regulating valve

Specifications Valve Shut Off Pressure

10 bar | 16 bar | 2.5 bar | 6 bar

Specifications Weight

115.0 kg

Specifications X

409 mm

Specifications Y

142 mm
