Yellow 3-Pin Wire Mount Socket Connector
Yellow 3-Pin Wire Mount Socket Connector
SKU:PRO-8ade3d
Reliable Yellow 3-Pin Wire Mount Socket Connector for secure sensor connections, ideal for AWG 24-26 wires. Meets institutional procurement standards.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Yellow 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Yellow 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Yellow 3-Pin Wire Mount Socket Connector is a high-quality solution for reliable sensor connections. With a maximum alternating current/direct current voltage of ~250V, this connector features a Terminal Material of C5210 with Gold plating for superior conductivity. The Body Material is made of Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) ensuring durability (UL94V-0 rated). This Sensor Connector meets institutional procurement standards, offering a secure connection with a minimum terminal retention of 1.4 kgf. Ideal for AWG 24 to 26 wires, this connector is designed for ease of use and longevity.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Yellow
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Yellow
Specifications Cover Diameter
1.0 to 1.2 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.13 to 0.21 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.13 to 0.21 mm²
Specifications Wire Size
26-24 AWG
