Yellow-Green 3-Pin Wire Mount Socket Connector
Yellow-Green 3-Pin Wire Mount Socket Connector
SKU:PRO-eaca9b
Reliable Yellow-Green 3-Pin Wire Mount Socket Connector for high-performance connectivity in institutional settings.
Regular price
$2.10
Regular price
Sale price
$2.10
Unit price
per
Initiate Order
Yellow-Green 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Claim Your Seller Account
Yellow-Green 3-Pin Wire Mount Socket Connector
$2.10
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Yellow-Green 3-Pin Wire Mount Socket Connector is a high-quality sensor connector designed for robust connectivity. With a maximum AC/DC voltage of ~250V and a maximum rated current of 3.0A, this connector is ideal for institutional and government applications. Constructed with C5210 gold-plated terminals and UL94V-0 rated Polycarbonate/ABS materials, it ensures reliable performance and durability. Meeting stringent industry standards, including FAR compliance and DLA standards, this connector offers secure wire connections with minimal extraction and maximum insertion force. Upgrade your connectivity solutions with this efficient and compliant wire mount socket connector.
Product Specifications
Specifications Body Material
Polycarbonate/Acrylonitrile Butadiene Styrene (ABS) (UL94V-0)
Specifications Case Material
Polycarbonate (UL94-V0)
Specifications Color
Yellow-Green
Specifications Connector Type
Wire Mount Socket
Specifications Cover Color
Yellow-Green
Specifications Cover Diameter
0.8 to 1.0 mm
Specifications List Price
2.10 USD
Specifications Maximum Alternating Current Acdirect Current Dc V
~250 V
Specifications Maximum Insertion Per Pin
1.96 N | 200 gf
Specifications Maximum Rated Current
3.0 A
Specifications Minimum Extraction Per Pin
0.49 N | 50 gf
Specifications Minimum Terminal Retention
1.4 kgf
Specifications Nominal Cross Section Area
0.05 to 0.08 mm²
Specifications Number Of Pins
3
Specifications Terminal Material
C5210 (Gold 0.2 μm)
Specifications Type
Sensor Connector
Specifications Weight
0.56 lb
Specifications Wire Cross Sectional Area
0.05 to 0.08 mm²
Specifications Wire Size
30-28 AWG
