Zephir® Electric Railcar Movers - Industrial Solution for Efficient Railcar Handling
Zephir® Electric Railcar Movers - Industrial Solution for Efficient Railcar Handling
SKU:ZEP-1ac2d0
Enhance railcar handling efficiency with Zephir® Electric Railcar Movers - perfect for institutional and government use.
Regular price
$28,999.00
Regular price
Sale price
$28,999.00
Unit price
per
Initiate Order
Zephir® Electric Railcar Movers - Industrial Solution for Efficient Railcar Handling
$28,999.00
Quantity: 1
Claim Your Seller Account
Zephir® Electric Railcar Movers - Industrial Solution for Efficient Railcar Handling
$28,999.00
Quantity: 1
Delivery via Maden
Expect your order to arrive on time.
Secure Payments
All orders are processed through a secure, PCI-compliant checkout.
The Zephir® Electric Railcar Movers are designed to streamline industrial railcar operations with precision and reliability. With a maximum drawbar pull of 11,690 lb·ft and dual-mode capabilities for road and rail operation, this mover ensures efficient transportation. Equipped with advanced safety features, such as directional signaling lights, emergency braking systems, and a centralized battery filling system, it meets strict industry standards for safety and performance. Ideal for government and institutional use, this electric mover offers unparalleled efficiency, versatility, and compliance with Federal procurement standards.
Product Specifications
Dimensions Height
104.3 in | 2650 mm
Dimensions Length
151.6 in | 3850 mm
Dimensions Width
86.6 in | 2200 mm
Note
Max performance on dry, flat and straight rail.
Options
Operator remote control (Hetronic)Interlock safety remote control system for Wheel Truing MachineCoupler based on customer requirementsHydraulic or manual slide for coupler height adjustmentDifferent rail gauge measuresRail track short-circuiting signaling systemPhotocell safety barrier - automatically stops machine in defined positionsPin type connectorsElectric winch for coupler liftingRubber buffersDistance proximity sensors with acoustic function (Rail mode)LED working lightsAir conditioning and heating systemArctic pack for cold environment
Standard Features Battery
80V 1,000Ah (40 cells - 2V per cell)On board battery charger with UL/CSA certified plug - 80V, 120A charging unitCentralized battery filling system with visual floater indicating battery fluid levelBattery charging time less than 8 hrs
Standard Features Brake
Rail modeFully proportional hydraulic power brake systemParking/Emergency brake - Spring applied hydraulic pressure releasedRoad modeDrum type brakes with independent hydraulic circuit brakeParking - Spring applied hydraulic pressure released
Standard Features Cabin And Driver Seat
Heavy-duty, insulated cabin with two lockable doors and full visibility from driver seatAdjustable driver seat with safety beltCameras and full-color display for easily positioning the machine on railCabin heater with temperature control dial
Standard Features Instrument Panel
User-friendly multifunctional panel with emergency recovery buttons
Standard Features Rail Mode Performances
Motor - 35 kW 80V - AC Brushless motorLarge 20.4" (520 mm) diameter rail wheels with steel guidance flange and replaceable high traction rolling surfaceHydraulic system for switching between road and rail modeMachine operates onboard cabin
Standard Features Rode Mode Performance
Motor - 7.5 kW 80V - AC Brushless motorFour (4) wheels. Front road wheels steer. Rear wheels provide traction.Shock absorbed by pre-charged nitrogen accumulatorsHydraulic power steering type on front wheels
Standard Features Safety Devices
Equipped with red and white directional movement signaling lights during rail modeHornAutomatic alarm while moving in road modeOrange beacon lightExterior emergency stop buttonsHand brake activation in case of low oil pressure in the braking systemEmergency braking system in case of failureSafety system to prevent sudden direction change during operationSafety system to prevent unit from switching on during recharge
Standard Features Traction Control System
Governed by a programmable micro PLC and high efficiency inverters
Standard Features Train Brake
Pneumatic braking system available.
Technical Specs Brands
Trackmobile® | Zephir®
Technical Specs Maximum Drawbar Pull
11,690 lb·ft | 52 kN
Technical Specs Rail Speed At Maximum Load
1.8 mph | 2.75 km/h
Technical Specs Standard Gauge
56.5 in | 1435 mm
Technical Specs Unloaded Rail Speed
4.9 mph | 7.5 km/h
Technical Specs Weight
19,850 lb | 9.9 US t
